Electric Guitar Amplifier - DUESENBERG BERLIN - Top + 1x12" Cabinet

large detail images:
det-duesenberg-berlin-top-cabinet.jpg duesenberg-berlin-top-front.jpg duesenberg-berlin-top-back.jpg duesenberg-berlin-top-diagonal.jpg
Large view Electric Guitar Amplifier - DUESENBERG BERLIN - Top + 1x12" Cabinet

not available - not available

This article is currently not available!!
Click on this link for similar offers

Duesenberg wrote:

The BERLIN is the new Duesenberg guitar amplifier and which will give you the ultimate in tone and power for any stage. The frame of this amp is made from wood which is then painted with a thin layer of metal particles. The metal coat is then processed and aged by hand, giving it the distinctive rusty patina which makes each build completely unique.

Inside, there is a 7025 High Grade combined with a 12AX7 for the preamp and two 6L6WGC tubes for the power amp. These are pushing all the raw tone straight to the speaker. We started with a clean channel and ended up with a great, bright and dynamic tone with straight forward Treble, Mid, Bass and Volume controls.
The internal boost section allows you to extend the clean channel. It boosts your clean signal without changing the overall texture of your tone. Additionally, the boost section can be fine tuned with Gain, Level and Contour controls.

The boost can be engaged by either using the switch on the front panel, or by using the included footpedal. You can choose if you want the overall boost to be “Hi-” or “Low-Gain” by preselecting your desired level at the back. This switch does not only set the headroom for your gain dial, it also changes the whole character of your boosted tone.

Of course you also get a passive serial effects loop, all the outputs you need (4/8/16 Ohm), a jack to plug in the included footpedal for your boost channel and a high quality Custom Duesenberg Softcover for both the amp and the cabinet. Handwired in Germany.

The cabinet is made from lightweight multi-ply birch and is painted and processed the same way as the amp itself. It has a semi open back and houses a Celestion Alnico Gold 8 Ohm Speaker with 50W power handling.

  • Amplifier:
  • Type : Single Channel + Boost Section
  • Power: 45 Watts
  • Tubes: 2 x 6L6WGC-STR / 1 x 7025 High Grade / 1 x 12AX7
  • Custom wound transformers (made in Germany)
  • Cascading gain structure
  • High dynamic clean channel, adjustable in Volume, Bass, Mid & Treble
  • Boost section extends clean channel, adjustable in Gain, Contour & Level
  • Two preselectable Boost gain levels on the rear pannel (hi/low gain)
  • Effects loop: Passive
  • Serial Outputs: 4/8/16 Ohms
  • Dimensions: 52.5 x 23 x 21 cm
  • Voltage: 230V
  • Cabinet:
  • Type : 1x12" semi open back
  • Wood: Light weight multiply birch
  • Speaker: Celestion Gold G12 8 Ohm, 50W power handling
  • Dimensions: 61 x 46 x 30 cm
  • Switch : Footswitch for boost (included)
  • Cover: Custom Duesenberg softcovers (included)
